ARM SERIES · HEAVY DUTY · 2017

DNOR Model 212K

The heavy-duty arm system for large and demanding gate installations, with manual keylock release for full control.

Manual keylock release
Dual-speed adjustment
72-hour backup battery

The 212K is the heavy-duty member of DNOR’s arm series — built for large and demanding installations, handling gate wings up to 3.5 metres and 350kg with adjustable force. Its electro-mechanical screw drive swings a 90° gate open in 9–13 seconds, faster than its lighter siblings.

The K stands for its signature feature: a manual keylock release that gives you full control of the gate whenever you need it. It retrofits into existing gates, and like every DNOR system it keeps working through blackouts on its rechargeable backup battery.

Best for

Large, heavy or oversized gates up to 350kg per wing
Bungalows, corner lots and commercial gateways
Owners who want keylock manual control

DNOR Model 212K full specifications

Power supply	AC 220V, 50/60Hz
Operating voltage	DC24V normal speed · DC12V cushioning speed
Max gate length	3.5 m per wing
Max gate weight	350kg per wing, force adjustable
Safety clutch	Electronic current sensing
Position limit device	Electronic fuzzy logic
Driving method	Electro-mechanical screw drive, piston type
Backup battery	12V 7AH rechargeable
Travel time (90°)	9 – 13 seconds
Working temperature	10°C to 50°C
Electronic controller	Micro-processor based
Weight	2.9 kg

Model 212K — common questions

What is the difference between the DNOR 212 and 212K?

The 212K is the heavy-duty version: a stronger motor for heavier gates, a faster 9–13 second travel time (vs 10–15 for the 212), and a manual keylock release. For large or heavy gates, choose the 212K; for typical residential gates the 212 is sufficient. Our full comparison covers it model by model.

How heavy a gate can the 212K handle?

Up to 350kg per wing with a maximum length of 3.5 metres per wing, with force adjustment to match the gate.

Can the 212K be fitted to my existing gate?

Yes — the 212K is designed to retrofit into existing swing gates, which makes it the usual upgrade path when an older or lighter-duty motor is struggling with a heavy gate.
