ARM SERIES · THE ORIGINAL · 2010

DNOR Model 712

The original DNOR arm motor — the machine that built the brand, still going strong on gates across three nations.

2 / 4-channel remote
Dual-speed adjustment
72-hour backup battery

The Model 712 is where DNOR began: the brand’s first arm motor, launched in 2010, and still in production because it simply keeps working. A side-mounted arm system with infrared sensor and 2- or 4-channel remote, it carries the widest working temperature range in the arm series — 0°C to 80°C — a legacy of being over-engineered from day one.

Speed adjustment cushions the gate’s opening and closing, an Allen key opens the gate manually during outages, and the rechargeable backup battery covers blackouts. Designed to last up to 10 years with regular basic care, many first-generation 712s are still on duty.

Best for

Owners who value the simplest, most proven DNOR system
Replacing an older 712 like-for-like
Standard residential swing gates

DNOR Model 712 full specifications

Power supply	AC 220V, 50/60Hz
Operating voltage	DC24V normal speed · DC12V cushioning speed
Max gate length	3.5 m per wing
Max gate weight	350kg per wing, force adjustable
Safety clutch	Electronic current sensing
Position limit device	Electronic fuzzy logic
Driving method	Electro-mechanical screw drive, piston type
Backup battery	12V 7AH rechargeable
Travel time (90°)	10 – 15 seconds
Working temperature	0°C to 80°C
Weight	3.2 kg

Model 712 — common questions

Is the DNOR 712 still supported?

Fully. The 712 remains in production, and parts and service are available through DNOR’s 500+ dealers across Malaysia, Indonesia and India.

Why choose the 712 over the newer 212?

Choose the 712 for its simplicity and its wide 0–80°C working temperature tolerance, or to replace an existing 712 like-for-like. The 212 is the newer everyday choice — our comparison post covers both in detail.
